Eizo RadiForce RX850 8MP 31.1" Fusion Color LED Mammo 3D-DBT Breast Imaging Display (RX850-BK)

Choose Your Option: RX850-BK-R

Eizo RadiForce RX850 8MP 31.1" Fusion Color LED Mammo 3D-DBT Breast Imaging Display (RX850-BK)

The RadiForce RX850 is changing the workstation paradigm by offering a multi-modality monitor that displays various color and monochrome imaging modalities on one screen. When efficiency is essential, viewing mammography-specific and PACS software applications on the same screen keeps radiologists from wandering the halls to their next read.

Optimum Breast Screening Monitor

Having received FDA 510(k) clearance for tomosynthesis and mammography from the U.S. Food and Drug Administration, the RadiForce RX850 can display MRI, CT, ultrasound images, and detailed breast screening images where high performance is essential. With multi-modality support, you can increase work efficiency to view numerous medical photos on one screen with exceptional accuracy.

Reduce Reflections for Image Clarity

Anti-reflection (AR) coating reduces reflections caused by outside light without affecting the monitor's light-emitting. This makes AR preferred over AG (anti-glare) treatments, which cause blacks to appear washed out due to diffusion of the backlight. Monitors with AR coating display digital mammography, chest X-rays, and other high-resolution images more clearly for accurate analysis.

RadiForce RX850 Improves Reader Efficiency

A research study by the University of Arizona Department of Medical Imaging demonstrated that a single RadiForce RX850 8-megapixel monitor significantly improves reader efficiency compared to a dual 5-megapixel RadiForce GX540 monitor configuration.

Streamline Your Workflow

Effectively replace a multi-monitor setup with an 8-megapixel screen capable of displaying all necessary image applications at once to streamline the radiology workflow.

View Fine Details Clearly

The super high-resolution screen displays 8 megapixels of information with a pixel pitch of 0.1704 mm for viewing medical images in exceptional detail. The monitor also offers a high contrast ratio of 1450:1 to render finer details accurately.

Keep Your Monitor Lit Longer

The LED backlight offers a significantly longer service life than conventional CCFL backlights. Also, 30,000 hours of usage time is guaranteed at the recommended brightness of 500 cd/m2.

Make the Precise Diagnosis

EIZO carefully measures and sets each grayscale tone to create a monitor compliant with DICOM Part 14. This ensures the most consistent shading possible, allowing for the most accurate diagnosis.

Manage Effortless Quality Control

A built-in Integrated Front Sensor (IFS) measures brightness and grayscale tones to calibrate to DICOM Part 14. The IFS does not interfere with the viewing area while cutting the workload and maintenance costs needed for monitoring quality control.

Conveniently View Images Side-by-Side

Two screens from separate input signals can be displayed simultaneously on one monitor. The widescreen enables flexible and straightforward operation without obtrusive bezels in between when viewing images side-by-side.

Optimize Color & Monochrome Brightness

When viewed on the same screen, the Hybrid Gamma function distinguishes between monochrome and color images, displaying each with optimal brightness and tones. This expands the usability of multi-modality applications by allowing an accurate review of a mix of color and monochrome images.

Create the Ideal Environment

The black front bezels are ideal for viewing the screen in dark reading rooms, making it easier to focus on images, while the original white stripe around the sides of the monitor presents a fresh, clean aesthetic.

View More Comfortably

The monitor's size was reduced to 37% less space than its predecessor, making viewing images on one screen more comfortable. Also, the thin bezels contribute to less head and eye movement when used with a worklist monitor.

Comfortably View from Any Angle

Wide viewing angles allow you to view the screen from the side with minimal color shift, also permitting more than one person to view the monitor comfortably at the same time.

Stay Confident With Stable Brightness

EIZO's confidence in its product quality extends to brightness stability, which is also covered during the usage time specified in the warranty.

View Accurate Images in Moments

The EIZO-patented drift correction function quickly stabilizes the monitor's brightness level upon startup or wake-up from sleep mode, giving you the most accurate images quickly ready for viewing. A sensor also measures the backlight brightness and automatically compensates for brightness fluctuations caused by ambient temperature and aging for a consistently stable display.

Attain Steady Images Across the Screen

The Digital Uniformity Equalizer (DUE) function helps to even out fluctuations in brightness and chroma on different screen parts to provide smoother images.

Select the Ideal Mode for Modalities

The CAL Switch function allows you to choose various modes for different modalities such as CR, CT, and endoscopy. It can be conveniently accessed using the monitor's front panel buttons to switch to optimal image viewing conditions easily.

Conserve Energy While Away

A presence sensor prompts the monitor to switch to power save mode when the user is away and resumes operation upon their return to conserve energy when not in use, uniting convenience with savings.

Improve operability

EIZO's highly versatile stand offers tilt, swivel, and a full-height adjustment range, enabling you to use the monitor with greater comfort.

Maintain the Precision

Perform a simplified calibration compliant with DICOM Part 14 using the bundled RadiCS LE quality control software. RadiCS LE corrects the monitor's brightness and grayscale tones to maintain image accuracy and consistency over time.

Tech Specs

Manufacturer Eizo
MFG. Part#. RX850-BK
Screen Type Color
Resolution 8MP (4096 x 2160)
Pixel Pitch 0.1704 x 0.1704 mm
Contrast Ratio 1450:1
Aspect Ratio Hv 17:9
Calibrated Luminance 500 cd/m²
Max Luminance 850 cd/m²
Calibration Auto (built-in front sensor)
Backlight Sensor Yes
Front Sensor Yes
Ambient Light Sensor Yes
Backlight LED
Screen Technology Monochrome (IPS)
Active Screen Size (DIAGONAL) 789 mm (31.1")
Active Screen Size (H x V) 697.9 x 368.0 mm (24.47 x 14.48")
Video Input Signals DisplayPort
3D Tomosynthesis Yes
Viewing Angle (H, V) 178°, 178°
Mount Type VESA (100 mm)
Dimensions (W x H x D) 747 × 449.5 - 593.5 × 281.5 mm (29.4" x 17.6" - 23.3" x 11")
Power Consumption 227 W
Power Requirements AC 100 - 120 V, 200 - 240 V: 50 / 60 Hz
Weight 49.38 lbs (22.4 kg)
