Barco® Coronis Fusion MDCC-4330 4MP 30" Color LED General Radiology PACS Display (K9301625A)


The Barco® Coronis Fusion MDCC-4330 is an advanced and versatile general radiology display monitor that combines images from diverse modalities—including CT, MR, and orthopedic images, in both color and grayscale—on a single screen for uninterrupted workflow and easy side-by-side image comparison. And it incorporates one-of-a-kind tools that will significantly boost your productivity and ability to unveil the most subtle details.

Comfortable, confident reading

In addition to the generous 30-inch screen size, the Barco® MDCC-4330 boasts features that reduce the strain associated with reading medical images and improve image quality:

  • IPS-Pro LCD technology that delivers consistent colors and grays, high contrast ratios, and wider viewing angles

  • Color uniformity correction at the pixel level (color PPU) to eliminate screen noise and achieve excellent image uniformity.

  • Ultra-bright calibrated luminance

  • The protective glass that envelopes the screen to reduce reflection


Heightened control and productivity

Work smarter and faster with the Barco® MDCC-4330. The fusion format means that you no longer have to switch between workstations. You can use the single-head workstation as two bezel-free heads or as one wide-screen workspace.

The MDCC-4330 incorporates Barco®-exclusive tools that improve your productivity and control over your workflow:

  • SpotView™ technology illuminates specific areas of interest while dimming the surrounding area to allow you to visualize abnormalities better.

  • DimView™ technology automatically dims the screens of nearby secondary displays used for patient worklists or dictation to minimize distractions.

Hassle-free compliance

Integrated MediCal QAWeb® software automates DICOM calibration and QA checks—without any requirement for user intervention—so that the Barco® MDCC-4330 produces top-quality imaging that meets all relevant standards, including those recommended by the American College of Radiology.

Barco®’s patented ambient lighting compensation (ALC) technology—a built-in, front-of-screen sensor—continuously detects changes in the surrounding lighting and automatically adjusts monitor brightness in real-time, in alignment with DICOM. The I-Guard® technology system further maintains compliance by correcting image quality, including color and grayscale values, in response to shifting light conditions around the workstation.

One-stop-shop solution

Barco®’s medical displays come with proprietary display controllers compatible with all major PACS workstations and applications. They contain seamlessly integrated technologies and features that enhance performance and functionality.

Longevity and low cost of ownership

Did you know that overheating is one of the most common culprits for damaging electronic components? With the Barco® MDCC-4330, you can enjoy a long display life and avoid the need to spend more on frequent maintenance and repair or early replacement. The MDCC-4330 uses mercury-free, energy-efficient LED backlights, which emit less heat, consume less power, and last longer. Temperature sensors also prevent the overheating of components.

Features at a Glance

  • Multi-modality imaging on one screen

  • Superior image quality

  • SpotView technology selectively brightens the details you want to view more closely.

  • DimView technology automatically lowers the brightness of auxiliary displays.

  • Continuous compliance with DICOM using integrated Medical QAWeb software as well as

  • I-Guard and ALC technologies


What's Included

  • Display Controller (Graphics Card)

  • Calibration Software

  • Accessories

Tech Specs

Manufacturer Barco®
MFG. Product Number K9301625A
Screen Type Color
Resolution Native 4MP (2560 x 1600) Configurable to 2 x 2MP+ (1280 X 1600) Configurable to 2 x 2MP (1200 X 1600)
Screen Technology IPS-TFT color LCD
Backlight Yes
Active Screen Size (DIAGONAL) 30.4'' (773 mm)
Pixel Pitch 0.256 mm
Viewing Angle (H, V) 178°
Backlight Censor Yes
Calibration Auto (built-in front sensor)
Calibrated Luminance 600 cd/m²
Max Luminance 1050 cd/m²
Contrast Ratio 1500:1
Video Input Signals DVI-D Dual Link (2x), DisplayPort (2x)
Weight 31 lbs (14 kg)
