Barco® Nio MDNG-6221 5MP 21" Grayscale LED Mammo 3D-DBT Breast Imaging Display (K9300372B)


Choose Your Option: K9300372B-N
Setup:
Price:
$17,999.99 $19,999.99
FREE SHIPPING
- +
+ -
Request A Quote
  • 5-Year Premium Warranty ?
  • 5-Year Hot-Swap Coverage ?
  • 30-Day Return Guarantee
  • Free Technical Support

Barco® Nio MDNG-6221 5MP 21" Grayscale LED Mammo 3D-DBT Breast Imaging Display (K9300372B)

$17,999.99
New / Pair
Carbon-neutral shipping with Shopify Planet
All deliveries are carbon neutral
Powered by Shopify Planet

Are you a radiologist focused on interpreting breast cases primarily through grayscale modalities, such as 2D mammography and 3D tomosynthesis? If so, the Barco® Nio MDNG-6221 Grayscale 5.8MP is tailor-made for your professional needs. This cutting-edge display system is packed with advanced features and innovations for today's breast imaging, ensuring an efficient and user-friendly experience. Moreover, it is ideally suited for reviewing high-resolution grayscale general radiology images.

Enhanced Image and Detail

Why opt for a Barco® MDNG-6221 display? In comparison to conventional 5.2MP systems, you'll enjoy 12% more pixels on your screen, which translates to increased detail visibility. Coupled with a tall 4:3 aspect ratio for viewing images in their entirety, you'll benefit from reduced panning and zooming efforts.

Dependable Image Quality

The Barco® MDNG-6221 delivers a higher number of Just Noticeable Differences, attributable to its superior brightness and contrast ratio. With integrated stability, calibration, and uniformity technologies, you can rely on consistent image quality, light output, and DICOM compliance throughout the years.

Streamlined Workflow

The Barco® MDNG-6221 goes beyond a standard grayscale monitor. It offers numerous customization options for settings, such as preferred white tints or viewing angles. Additionally, our MXRT medical display controllers provide a set of Intuitive Workflow Tools to enhance your efficiency and expedite your reading process.

Did you know SpotView enables you to double the brightness of a selected area?

This feature has been proven to reduce radiologists' reading time by up to 15.5%. You can also create user profiles for shared displays, streamlining the adjustment process for multiple users.

Extended Lifespan and Uncompromised Clarity

The Barco® MDNG-6221 meets the latest medical standards for European medical devices and MQSA in the United States. It's effortless to install our free, highly secure QAWeb Enterprise application, ensuring remote quality assurance without interventions. This tool simplifies PACS management by enabling centralized management of Barco® displays' uptime and compliance - anytime, anywhere.

In summary, the Barco® MDNG-6221 monitor is a versatile, user-friendly diagnostic display system, keeping pace with modern innovations in general grayscale radiology and 2D/3D mammography.

Features

  • Expanded screen detail with 5.8MP resolution
  • 3:4 aspect ratio designed for complete breast image display
  • Enhanced contrast through a 1400:1 contrast ratio and 600 to 1000 cd/m² calibrated luminance
  • Uniform Luminance Technology and SteadyGray ensure consistent brightness and grays
  • Stable DICOM images and automatic QA with I-Guard front sensor and optional QAWeb Enterprise
  • Luminance boosting capabilities with I-Luminate and SpotView
  • Customizable settings and tools to adapt the monitor to your workflow, courtesy of Intuitive Workflow Tools

Tech Specs

Manufacturer Barco®
MFG. Part#. K9300372B
Screen Type Grayscale
Resolution 5.8 MP (2100 x 2800 pixels)
Pixel Pitch 0.1545 x 0.1545 mm
Contrast Ratio 1400:1
Aspect Ratio Hv 3:4
Calibrated Luminance 600 cd/m²
Max Luminance 1300 cd/m²
Calibration Auto (built-in front sensor)
Backlight Sensor Yes
Front Sensor Yes
Ambient Light Sensor No
Backlight LED
Active Screen Size (DIAGONAL) 541 mm (21.3")
Active Screen Size (H x V) 324 x 433 mm (12.77" x 17")
Video Input Signals DisplayPort
3D Tomosynthesis Yes
Viewing Angle (H, V) 178°, 178°
Mount Type VESA (100 mm)
Dimensions (W x H x D) 378 x 528 x 235 mm (14.8" x 20.7" x 9.2")
Power Consumption 60 W
Power Requirements 100–240 VAC, 1.9–0.8 A, 50/60 Hz
Weight 22.4 lbs (10.2 kg)
