The MUIP-2112 is an optimal choice of smart touch user interface for image-guided therapy in cath labs, hybrid ORs, and robotics-assisted surgery, using scientific and objective language to build reader trust.
Achieve complete command with a single touch.
The MUIP-2112 boasts compatibility with cart-based systems, mobile X-rays, and ultrasound, in addition to a standard VESA interface for straightforward mounting on carts, arms, or booms. Its anti-glare front glass and impressive brightness make it well-suited for use in brightly lit spaces such as operating rooms or cath labs.
The 12.5-inch touchscreen, with P-Cap Multi-Touch technology, guarantees smooth operation of the user interface, even with medical gloves. The superior optics presenting a high contrast ratio and a broad viewing angle render the interface clearly visible and controllable from any position.
Clinically authorized and swiftly verified.
Barco®'s MUIP-2112 adheres to stringent medical standards and modern design guidelines. Its fanless build diminishes dust and bacteria, while its IP-54 front and IP-x3 back ratings guarantee hygienic and safe cleaning and handling.
Constructed in compliance with the strictest standards, the MUIP-2112 enables expeditious examination of the device in any medically-oriented environment. It can be connected to medical imaging systems either via an Ethernet cable or a wireless connection.
- Anti-glare glass front screen
- P-Cap Multi-Touch technology
- Fanless design
- VESA 75 mounting interface
- Ultra low-power CPU board
- Modular and versatile CPU platform
- Protected front (IP54) and back (IP21)
|Resolution||1920 x 1080|
|Calibrated Luminance||400 cd/m²|
|Max Luminance||400 cd/m²|
|Ambient Light Sensor||No|
|Active Screen Size (DIAGONAL)||317.5 mm (12.5")|
|Active Screen Size (H x V)||276.5 x 157.5 mm (10.8" x 6.2")|
|Viewing Angle (H, V)||± 80° (H & V, minimum)|
|Mount Type||VESA (100mm)|
|Dimensions (W x H x D)||312 x 200 x 37 mm (12.2" x 7.8" x 1.4")|
|Power Requirements||AC 120/230 V|
|Weight||3.08 lbs (1.4 kg)|
