One Monitor, Multi-Image
JVC Totoku CL-S1200 can accommodate images from any modality, including Digital Mammography/Tomosynthesis, US, CT, MRI, and pathology.
The Dynamic Gamma function (patented No. 6277984) can automatically identify monochrome and color images' pixels to display each of them in the optimum gradation. Auto Config Select function can read the DICOM information of images to switch the configuration at the best performance.*
Focus on Details
Using Visual Point Mode, you can focus on the detail where you want to see (4 options of area shape). It can also be used in combination with the Turbo Luminance function.
The Turbo Luminance function can boost screen brightness and contrast to the maximum of 30 seconds to magnify identifiable grayscale gradations, contributing to finding out low contrast lesions on mammograms.
Reduce Eye Strain
A medical monitor usually comes with high luminance, which is not comfortable for text reading. With Auto Text Mode, brightness is automatically adjusted on patient lists and reporting applications to reduce eye strain.
The stabilization system for luminance and color temperature can automatically adjust luminance and color temperature in real-time. The built-in Color Front Sensor on the screen realizes constant measurement of color temperature. It adjusts the color temperature changes due to long-term use that the movable front sensor cannot.
Integrated QA Solution
Managing the daily operation of the Radiology department is now more simplified with QA Medivisor Agent’s calibration and QA standard testing capabilities, combined into an intuitive and easy-to-navigate user interface. This includes QA Medivisor Agent LE, a simplified calibration scheduling tool.
*Optional calibration kit CAL-016 is required for standard QA testing.
The built-in Rear Light on the back of the monitor provides an eye-friendly environmental illuminance as indirect lighting. The built-in Reading Light on the bottom illuminates the keyboard and mouse. The brightness of both lights can be adjustable to support working in the darkroom.
The JVC CL-S1200 includes several front sensors to efficiently adjust your monitor to fit any reading environment. An ambient light sensor offsets the effects of ambient light to ensure optimal calibration, a color front sensor stabilizes luminance and color for consistent image quality, and the human presence sensor automatically switches to power save mode when you're away.
Easy to Keep Clean and Hygienic
An anti-reflection glass filter covers the surface of the LCD. Noiseless design with few irregularities and gaps along with the wide-angle swivel, it is easy to wipe the main body to keep clean and hygienic.
A 30.9-inch widescreen with a high resolution of 12 million pixels realizes 12% of space-saving than the use of two conventional model 5-megapixel monitors side by side, contributing to expanding the workspace on the desk.
Simple Wire Management
CL-S1200 can display a 12-megapixel high-resolution image with a single DisplayPort 1.4a cable.* It's also applicable for two cables of DisplayPort 1.2. Owing to the DisplayPort, daisy chains can be realized for simple wiring connections. Also, a wire hole in the stand helps reduce the cable's load and raise, lower, rotate the screen smoothly.
*Special graphics card is needed.
Docs & Drivers
|MFG. Product Number||CL-S1200|
|Resolution||12MP (4200 x 2800)|
|Screen Technology||30.9-inch, color, TFT, IPS technology|
|Active Screen Size (H x V)||652.68 x 435.12 mm (25.7 x 17.13")|
|Ambient Light Sensor||Yes|
|Active Screen Size (DIAGONAL)||784.9 mm (30.9")|
|Pixel Pitch||0.1554 × 0.1554 mm|
|Viewing Angle (H, V)||178°, 178°|
|Calibration||Auto (built-in front sensor)|
|Calibrated Luminance||600 cd/m²|
|Max Luminance||1200 cd/m² (typical), 600 cd/m² (calibrated)|
|Contrast Ratio||1500:1 (typical)|
|Power Consumption||95 W|
|Video Input Signals||2 x DisplayPort (DisplayPort 1.4a compliant)|
|Weight||34.4 lbs (15.6 kg)|
|Recommended For||Digital Mammography, 3D, General Radiology|
